Automatic PVC/POF/PE Film Wrapping Machine and Heat Shrink Machine Bottle and Box L Sealing Shrink Wrapping Machine
The automatic film-sleeving machine features a high degree of automation, utilizing precise photoelectric sensors for accurate film application as well as automatic sealing and cutting. It is easy to set up and adjust, capable of accommodating a wide range of product specifications and various types of shrink films. The equipment operates with exceptional stability, effectively reducing labor costs, and produces neatly and uniformly packaged finished goods, making it ideally suited for high-volume, assembly-line operations.
The heat-shrink machine employs a hot-air circulation design, ensuring precise temperature control and uniform heat distribution. Following the shrinking process, the film adheres tightly to the product, free of any bubbles or wrinkles. Built for durability and ease of operation, the machine supports continuous, long-duration operation and can be seamlessly integrated with the film-sleeving machine to form a complete packaging production line.
Film Wrapping Machine and Heat Shrink Machine: Key Features
Product Details
Machine Specifications
| Material | High-quality stainless steel SUS304 | ||
| Main components | The Film Wrapping Machine and Heat Shrink Machine consists of temperature controller, heating tube, Motor, Conveyor Needle Rollers, Sealing Knife control system, electrical components, etc. | ||
| Applicable packaging materials | such as POF, PVC, and PE,etc. | ||
| Packaging size | Length 420mm, Width 400mm, Height 150mm (customized according to the packaging material size provided by the purchaser) | ||
| Working air pressure | 0.6mpa | ||
| Packaging speed | 20-50 packs/minute. | ||
| PLC control and servo system | Mitsubishi or others | ||
| Customization | Available in various Packaging size,designs, function and branding options | ||
General Application
Machine Advantages
Customization Options
Packaging & Logistic
Film Packaging Machine Videos
Frequently Asked Questions
Film Wrapping Machine and Heat Shrink Machine
Can the temperature be freely adjusted?
Yes, it features intelligent digital temperature control, allowing for independent adjustment of both temperature and conveyor speed. It is compatible with various materials, including thin films, thick films, and large-format PE films.
What types of shrink film does the machine support?
It supports commonly used heat-shrink films available on the market—such as POF, PVC, and PE—as standard. Switching between film materials requires no machine modification; you can simply adjust the parameters to begin operation.
What are the functions of shrink packaging?
It protects products from dust, moisture, loosening, and scratches; it compacts the packaging volume; it provides an aesthetic, premium appearance; and it simultaneously saves space in storage and logistics.
Why is a heat shrink machine still required after the film has been applied?
The film wrapping machine is solely responsible for applying the film and performing the sealing and cutting operations; consequently, the film remains in a loose state. A heat shrink machine is necessary to apply high heat for shaping and setting, thereby ensuring a tight, snug fit that is both smooth and aesthetically pleasing.
What causes uneven shrinkage results in a heat shrink machine?
The equipment features a comprehensive hot air circulation design, ensuring uniform heating under normal operating conditions. Uneven shrinkage typically occurs when the temperature and speed parameters are mismatched; this issue can be resolved by making minor parameter adjustments.
Which products are suitable for use with an automatic film wrapping machine?
It is suitable for regularly shaped full cartons and individual items—such as cardboard boxes, gift boxes, bottled goods, boxed products, daily necessities, hardware, and food items. Highly versatile, it can effectively wrap the majority of standard products.
Get a free quote
Please fill out the form below to request detailed information about our advanced cosmetics machinery.
Our team at FULUKE will respond promptly to assist you with customized solutions for your production needs.
